Input voltage: 3 – 32V

Output voltage: 5 – 35V (adjustable)

Output current: Maximum output current 4A

Note: The higher the voltage, the load current increases.

Efficiency of this regulator upto <94%

Load regulation: 0.5%

Voltage regulation: 0.5%

Adjustable potentiometer onboard for output voltage adjustment.

Non – isolated constant voltage module.

Non – synchronous rectification.

Short circuit proportion: current limiting since the recovery.

Dimension: 45*20*14 mm (L*W*H)
